Description

Pipe welding line is the main equipment for producing straight seam welding tubes in many departments, such as metallurgy, machinery, light industry, and building materials, etc. It can be used to manufacture profiled pipes as well as round pipes. As a professional tube welding machine manufacturer in China, our line is to produce Φ115-Φ219mm and δ2.0-5.0mm high-frequency straight seam welded pipe, square pipe and special-shaped pipe (δ≤4.0mm).

Manufacturing Process

Manufacturing process of pipe welding line is composed of uncoiling, molding, welding, polishing, sizing, straightening and cutting, etc. Rolling speed can be adjusted correspondingly within proper range of pipe diameter and wall thickness.

Features

Description Carbon steel pipe welding line
Diameter of welded tubes Φ40-115mm
Wall thickness of welded tubes 1.5-5.0mm
Speed of tube welding 15-60M/min
Power of major motor 132KW×2
Power of high frequency welder 400KW
1.Tube welding machine is endowed with high quality. By taking advantages of same kind machines at home and abroad, our products are popular with customers.
2.Our pipe welding line is with long working life.
3.All of our products are with excellent performance at low cost.

Technical specifications

Description	Carbon steel pipe welding line
Diameter of welded tubes	Φ40-115mm
Wall thickness of welded tubes	1.5-5.0mm
Speed of tube welding	15-60M/min
Power of major motor	132KW×2
Power of high frequency welder	400KW

Maintenance and transportation:
User shall regularly lubricate chain wheel, bearings and speed reducer, etc. and keep clean of forming rollers.

We are with favorable geographic location and convenient transportation, which can shorten the delivery time and lower the freight charge.
