Description
We are renowned for our diameter Φ25.4-50.8mm stainless steel pipe welding machine which is designed to produce pipes/tubes of Φ25.4mm-Φ50.8mm and thickness range of 0.8mm-2.0mm. We also can perform production in accordance with customers’ needs.
Feature
Stainless steel pipe welding machine is made by refined materials in high precision and equipped with computer fixed length cutting saw. Rolling speed can be adjusted correspondingly within proper range of pipe diameter and wall thickness.
Advantages
1. Our products are manufactured with best materials, thus they are steady, durable and with long working life.
2. It is easy to control and operate stainless steel pipe welding machine.
3. It is easy to replace mould, which saves working hour and improve working efficiency.
Technical specifications
|
Description
|
stainless steel pipe welding machine
|
|
Item
|
Maxtube-bg20
|
Maxtube-bg40
|
Maxtube-bg60
|
|
Diameter of welded tubes
|
Φ8-25.4mm
|
Φ25.4-50.8mm
|
Φ38.1-76.2mm
|
|
Wall thickness of welded tubes
|
0.5-1.0mm
|
0.8-2.0
|
1.0-3.0
|
|
Speed of tube welding
|
0.5-8M/min
|
0.5-6M/min
|
0.5-4M/min
|
|
Ar-arc welder
|
400A
|
600A
|
600A
|
Maintenance and transportation
User shall regularly lubricate chain wheel, bearings and speed reducer, etc. Forming rollers shall be kept clean.
